ADB products
PathogenFocus currently offers several products for Air Disinfection Biosecurity (patent pending) technology. The ADB 7000-AF series works in conjunction with your existing HVAC units. This series features several different models of different sizes and capabilities, which are noted in detail on the product spec sheet. These units are capable of providing disinfection for large volume areas. The ADB 7000-T series utilizes an integrated turbine to draw air into the unit. These units are available in three sizes and a wide range of duty cycles for maximum versatility. The ADB 7000-W is a wall-mounted unit that works independently from the HVAC system. The ADB 7000-W provides disinfection from a lightweight, easy-to-install unit. The ADB 7000-P is our portable biosecurity unit. This unit provides anti-pathogen capabilities like the others, but comes in a lighter, portable package. Like the ADB 7000-W, the ADB 7000-P works independently from your HVAC system. More details below. The ADB 7000-WP is a similar unit to the 7000-W, in that it can also be wall-mounted, but also ships standard with a convenient carrying handle like the 7000-P for added portability.
JUMP TO A PRODUCT: ADB 7000-AFÂ |Â ADB 7000-TÂ |Â Â ADB 7000-WÂ |Â ADB 7000-WPÂ |Â ADB 7000-P
The ADB 7000-AF series works in conjunction with your existing HVAC system to provide Air Disinfection Biosecurity. This series provides a comprehensive disinfection solution for use in public spaces to achieve a new air quality safety threshold. It accomplishes this by neutralizing up to 99.99 percent of viruses and bacteria. These units are pre-programmed to operate based on factory settings that regulate the production level of the system automatically. Each system is process engineered for the space being treated to ensure continuous and proper treatment throughout the space.
- \Models: Four different models (1AF, 2AF, 4AF, 8AF), see spec sheets for details on each
- Operational Frequency: 50/60 Hz
- Amps: Varies on the model, ranging from 0.125A up to 0.46A
- Power: Varies depending on the model, ranging from 15W to 55W
- Voltage: 120V
- Construction: Cabinet constructed of powder coated aluminum
- Output: 3" PVC reaction chamber on 1AF model. 4" PVC reaction chamber on all other models, with 3" PVC reducers included
- Weather Guard Enclosure (WGE) available for outdoor installations. These enclosures provide protection for the ADB 7000-AF from the elements - rain, sleet, snow. Click here for the WGE spec sheet.
ADB7000-2AF
The ADB 7000-T series features an integrated turbine that draws air into the unit and distributes treatment into the space. Additional equipment may be necessary to evenly distribute the treatment throughout the space (i.e. fans, piping/ductwork). A MERV 11 filter keeps the reaction chamber clean and working properly. Filter must be changed every 90 days at minimum. With three different model sizes and multiple output options for each, the ADB 7000-T is capable of providing treatment to a wide range of spaces.
- Models: Three different size models to handle a wide range of spaces, see spec sheets for details on each
- Operational Frequency: 50/60 Hz
- Amps: Varies on the model, ranging from 0.28A up to 0.38A
- Max Power: Varies depending on the model, ranging from 33W to 45W
- Voltage: 120V
- Construction: Cabinet constructed of powder coated aluminum
- Output: 3" PVC outlet
ADB 7000-4T
The ADB 7000-W is a wall-mounted ADB unit that provides continuous and proactive 24/7, 365 air and surface disinfection. These units do not integrate with HVAC duct work, but rather provide independent disinfection. The ADB 7000-W can be used to provide a comprehensive disinfection solution for use in public spaces to achieve a new air quality safety threshold. This lightweight product features an easy-to-use wall mount bracket for simple installation.
- Operational Frequency: 50/60 Hz
- Amps: 0.1A
- Max Power: 12W
- Voltage: 120V
- Cabinet Construction: Cabinet constructed of powder coated aluminum
- Turbine CFM: 112.9
ADB 7000-W
The ADB 7000-WP is a combination wall-mounted or portable unit. This unit ships standard with a mounting plate for easy wall-mounting. A convenient carrying handle adds portability. This versatile unit is available in fixed or selectable outputs for maximum versatility. It can provide continuous and proactive 24/7, 365 air and surface disinfection. Like the ADB 7000-W, these units do not integrate with HVAC duct work, but provide independent disinfection.
- Operational Frequency: 50/60 Hz
- Amps: 0.1A
- Max Power: 12W
- Voltage: 120V
- Cabinet Construction: Cabinet constructed of powder coated aluminum
- Turbine CFM: 112.9
ADB 7000-WP
The ADB 7000-P series is a portable unit that works independently of your HVAC system. Like the ADB series, the ADB 7000-P provides a comprehensive disinfection solution for use in public spaces to achieve a new air quality safety threshold. It accomplishes this by neutralizing up to 99.99 percent of viruses and bacteria. These units are pre-programmed to operate based on factory settings that regulate the production level of the system automatically.
- Operational Frequency: 50/60 Hz
- Amps: 0.17A
- Max Power: 20W
- Voltage: 120V
- Dimensions: 16.25 inches long, 4.75 inches wide, 7.5 inches tall
- Weight: 8.6 lbs.
ADB 7000-P
Installation Photos
ADB7000-WP installed in a conference room (click to expand)
